Elcometer 130 Salt Contamination Meter – Soluble Salt Testing

The Elcometer 130 Salt Contamination Meter quickly and accurately measures the level of soluble salts on surfaces.

The Elcometer 130 soluble salt profiler provides fast and accurate measurement of the level and density of soluble salts – over 4 times faster than other Bresle-equivalent methods.

ELCOMETER 130 MODEL SPECIFICATIONS

• Model S Quickly and accurately measures the level of soluble salts on surfaces over 4 times faster than Bresle equivalent test methods. Add to cart
• Model S Certified Add to cart
• Model T Accurately measures the level of soluble salts on surfaces over 4 times faster than Bresle equivalent test methods. Allowing 100,000 readings to be stored in 1,000 batches and allow the user to view on screen statistics. Add to cart
• Model T Certified Add to cart

Four Bresle equivalent readings in 2½ minutes

Each filter paper is the size of four Bresle patches – the Elcometer 130 Soluble Salt Profiler not only displays the individual reading but also provides four Bresle equivalent readings in just over two minutes.

The new Elcometer 130 SSP doesn’t just measure the level of soluble salts

In addition to soluble salt levels (cleanliness) or conductivity, the Elcometer 130 SSP carries out a detailed analysis of the test area – providing an accurate salt density profile map, pinpointing areas of high contamination outside user-defined limits.

Accurate in all environments

This new, easy-to-use Elcometer 130 SSP has automatic temperature compensation, ensuring accuracy in all climatic conditions. Impure water can be offset for accurate and repeatable readings. “Each gauge is designed to last.” Robust, durable & water-resistant, the new Elcometer 130 SSP is available with a 2-year manufacturer’s warranty, giving you peace of mind.

Generate instant reports on your PC, Android™ or iOS mobile device

The Elcometer 130 SSP wirelessly transmits readings, statistics and batches via Bluetooth® or via USB straight into an inspection application or into ElcoMaster ®, Elcometer ’s Mobile App, for instant report generation at your desk or, using your mobile, in the field.

Calibration verification – peace of mind

A Calibration Verification Tile is available for verifying the accuracy of the gauge whilst out in the field and the verification data is recorded for use in reports

Can be used in accordance with SSPC Guide 15

What makes Elcometer 130 so efficient?

1. Fast reaction time
2. Dust and water resistant rugged design equivalent to IP64ding rate allows multiple tests to be completed efficiently
3. Pressure plate ensures a constant and uniform pressure to paper
4. Automatic detection of paper size and automatic adjustment of reading value
5. USB and Bluetooth® data output to ElcoMaster™ 2.0 software
6. Dust and water-resistant rugged design equivalent to IP64
7. Automatic temperature compensation ensures accurate results
8. Non-oxidizing gold plated contacts ensures lifetime accuracy
9. Stores up to 150,000 readings in 2,500 alphanumeric batches
10. Fully portable hand-held, an ergonomic design ideal for use in the field

Figure 1 – The saturated filter paper extraction method
	Fill the syringe with 1.6 ml of high purity water.   Note: Non-pure water (up to 2µg/cm²) can be automatically offset with the gauge.
	Eject the 1.6ml on to a clean unused sample paper, taking care to retain all the water on the paper.
	Place wetted paper on to the area under test, pressing firmly into contours and irregularities to remove any entrapped air. Start the timer on the gauge. Whilst waiting for the sample time to elapse, additional tests can be prepared.
	After 2 minutes, remove the paper from the surface and place it on to the gold-plated electrodes.
	Close the lid, ensuring that the magnetic catch is fully engaged.   The reading will automatically be displayed and stored into memory together with paper size, temperature, date and time.
	The reading will be displayed.
