Ultrasonic Corrosion Mapping Gauge CG100ABDL+

$3,671.50 CAD

  • Measure up to 500mm (20”) of a user-defined material
  • Color screen
  • 210,000 reading memory
  • 64 User-defined setups
  • Multiple language display
  • Multiple calibrations and material selection options
  • High-speed scan mode: 32 readings per second
  • Differential and minimal thickness alarm modes

This State-of-the-Art thickness gauge stores up to 16,000 readings with individual waveforms in alphanumeric batches and full data logging through RS232 data output to Elcometer NDT data management software.

Perform ultrasonic corrosion mapping with ease on projects big and small.

Offering a full range of measurement modes including Pulse-Echo Temp Comp Mode (PETP) and Coating Only Mode (CT) to Pulse-Echo Coating Mode (PECT) for Ultrasonic Corrosion Mapping, the CG100 range of handheld corrosion thickness gauges allows the inspector to choose the right tool for the job.

Featuring automatic gain control (AGC) for ease of use or manual adjustment (-30dB to 70dB) to increase the amplitude of the received echo to suit the material properties, the CG100 ABDL+ coating thickness gauge is ideal for all applications.

The time corrected gain (TCG) feature automatically compensates for sound attenuation through a material, further increasing the performance of the gauge.

Built-in Gates allow users to set the measurement parameters either on or between waveforms, bypassing any surface echoes or noise from the material.

Threshold adjustment allows users to adjust the sensitivity of the gauge to detect signals with lower amplitudes.

The CG100ABDL+ thickness gauge stores up to 16,000 readings with individual waveforms in alphanumeric batches and full data logging through RS232 data output to Elcometer NDT data management software.

With its high contrasting color display, the CG100ABDL+ thickness gauge has a refresh rate of 120Hz providing users with an instant measurement response.

Advantages

  1. Range of display & measurement options: Pulse-Echo, Echo-Echo, Pulse-Echo Temp, Comp Mode (PETP), Coating Only Mode (CT), Pulse-Echo Coating Mode (PECT)
  2. Adjustable gain: -30dB to 70dB range
  3. Automatic gain control (AGC)
  4. Time corrected gain (TCG)
  5. Gate control
  6. Threshold adjustment
  7. 64 User-defined setups
  8. Multiple language display
  9. Multiple calibrations and material selection options
  10. High-speed scan mode: 32 readings per second
  11. Differential and minimal thickness alarm modes
  12. Data output and storage: 16,000 readings and waveforms or B-Scans
  13. Data management software

Specifications – ultrasonic corrosion mapping gauge

Model & Part Number CG100ABDL Corrosion Thickness Gauge
Material thickness digits display
B-Scan cross-sectional display
Combined B-Scan and digits display
Scan bar display
Coating thickness display
A-Scan Display  + Rectified, – Rectified, Full Waveform (RF)
Measurement Mode PE, PETP (Temp Compensation),
EE (ThruPaint™), EEV, CT (Coating) & PECT
Measurement Rate
Manual:
Scan mode
Scan bar display
4 readings per second
32 readings per second
6 readings per second
Measuring Range PE: 0.63 – 508mm (0.025 – 19.999 inches)
PETP: 0.63 – 508mm (0.025 – 19.999 inches)
EE: 1.27 – 102mm (0.050 – 4.000 inches)
EEV: 1.27 – 25.4mm (0.050 – 1.000 inch)
CT: 12.7 – 254μm (0.0005 – 0.100 inch)
PECT: 0.63 – 508mm (0.025 – 19.999 inches)
PECT: 0.01 – 2.54mm (0.0005 – 0.100 inch)
Measurement Accuracy ±0.01mm (±0.001 inch)
Measurement Resolution 0.01mm (0.001 inch)
Velocity Calibration Range 1250 – 9,999m/s (0.0492 – 0.3936in/ms)
Additional Features:
High speed scan mode
Differential mode
Limit alarm mode
B-Scan display speed adjustable display speed
Flaw mode Basic prove-up flaw detection using
single element angle beam transducers
Calibration setups 6 factory & 64 user-definable setups
transferrable to and from a PC archive
Gates 3 fully adjustable gates:
start, stop, width & threshold
Damping adjustable; impedance matching for
optimizing transducer performance
Pulser type dual 200-volt square wave pulses with adjustable
pulse width (spike, thin, wide)
and 50-volt cut/boost for greater penetration
Gain manual, automatic gain control (AGC)
with 110dB range (limited),
time corrected gain (TCG)
Timing precision 25MHz TCXO with a single shot
100MHz 8bit ultra-low-power 8-bit digitizer
Data logging 8,000 with A/B-scan image & gauge settings
210,000 – coating, material, min, max thickness
sequential and grid logging
Alphanumeric batch identification
OBSTRUCT indicates inaccessible locations
Calibration Options single, two-point, velocity & material type
Transducer Probe Type dual element & flaw prove up
Transducer Frequency Range 1 – 10MHz
Transducer recognition automatic & manual – selectable from a list
V-path / dual path error correction automatic
Probe zero automatic & manual (via integrated probe disk)
Display 1/4 VGA AMOLED color display
57.6 x 43.2mm (2.27 x 1.78inch) viewable area
Display Refresh Rate 120Hz
Units (selectable) mm or inches
Backlight adjustable brightness
Repeatability / Stability Indicator
Battery Type 3 x AA alkaline
Battery Life (approximate) 25 hours
Low Battery Indicator
Battery Save Mode auto
Operating Temperature -10 to 60ºC (14 to 140ºF)
Size (w x h x d) 63.5 x 165.0 x 31.5mm (2.5 x 6.5 x 1.24 inches)
Weight (including batteries) 383g (13.5oz)
Aluminum case design with the gasket-sealed end
caps, waterproof membrane keypad
Transducer Connector Type LEMO
RS232 Interface Bi-directional
Packing List Elcometer NDT CG100ABDL+ gauge, couplant, carry
case, user manual, test certificate,
3 x AA batteries, software, transfer cable

Download Datasheet

Download Instructions Manual
